VIANS VI-701 Fail Secure Short Panel Electric Strike

Features

• Adjustable Electric Strike with Narrow Frame: Designed to fit a variety of door types, offering flexibility in installation.
• Works with Mechanical Lock: Can be used alongside mechanical locks for enhanced security.
• Anti-Residual Magnetism Design: Prevents the strike from retaining magnetism after release, ensuring smooth operation.
• Supports Doors with 90° Opening: Compatible with doors that open up to 90 degrees, allowing for greater flexibility in door swing.
• Made from Hardened Stainless Steel: Built to withstand heavy-duty use, capable of bearing up to 500 kg of impact pressure, ensuring durability and security.

Specifications

• Model: VI-701
• Product Name: Short Panel Electric Strike
• Lock Size: 160L x 25W x 31H (mm)
• Holding Strength: 500 kg
• Input Voltage: DC 12V ± 10%
• Working Current: 200 mA
• Opening Mode: Supports 90° Swing Door
• Bolt Housing: Stainless steel, with silk polishing for a smooth finish
• Strike Structure: Stainless Steel for durability and resistance
• Applicable Door Types: Suitable for wooden doors, glass doors, metal doors, and fireproof doors
• Signal Output: None
• Feature:
  • Fail Secure (NO): Strike remains locked when power is off
  • Fail Safe (NC): Strike unlocks when power is off
• Surface Temperature: Within +20℃
• Suitable Temperature Range: -10℃ to +55℃ (14℉ to 131℉)
• Weight: 0.35 kg
• Standard Package: 70 PCS per carton
• Carton Weight: 24.5 kg
• Carton Size: 54.5 x 20 x 30.5 cm
