🔋 51.2V 300Ah

Item	Specification
Rated energy (kwh)	15.36KWH
Configuration	1P 16S
Nominal Voltage (V)	51.2V
Working Voltage (V)	42V~58.4V
Nominal Capacity (Ah)	300Ah
Rated charging/discharge current (A)	100A/200A @25±2℃
Maximum charge current (A)	200A @25±2℃
Maximum discharge current (A)	200A @25±2℃
Working Temperature	0~40℃ (Charge)
	-20~60℃ (Discharge)
Humidity (%)	5%~95%
Altitude Limited (m)	0~3000m
Weight (Kg)	113kg±3kg
Dimension (mm)	774415270mm
Storage temperature and humidity	-10℃~35℃ (Within one month of storage)
	25±2℃ (Within three months of storage) 65%±20%RH
Cycle life	6000 cycles @25℃
	50A Charge and discharge current 80%DOD
IP grade	IP20
Communication mode	CAN&RS485

🔋 51.2V 200Ah

Item	Specification
Rated energy (kwh)	10.24kwh
Configuration	1P 16S
Nominal Voltage (V)	51.2V
Working Voltage (V)	42V~58.4V
Nominal Capacity (Ah)	200Ah
Rated charging/discharge current (A)	50A/100A @25±2℃
Maximum charge current (A)	100A @25±2℃
Maximum discharge current (A)	100A @25±2℃
Dimension (mm)	400206680mm
Weight (Kg)	100kg
Cycle life	6000 cycles @25℃
IP grade	IP20
Communication mode	CAN&RS485

Item	Specification
Rated energy (kwh)	5.12kwh
Configuration	1P 16S
Nominal Voltage (V)	51.2V
Working Voltage (V)	42V~58.4V
Nominal Capacity (Ah)	100Ah
Rated charging/discharge current (A)	50A @25±2℃
Maximum charge current (A)	100A @25±2℃
Maximum discharge current (A)	100A @25±2℃
Dimension (mm)	375178625mm
Weight (Kg)	48kg
Cycle life	6000 cycles @25℃
IP grade	IP20
Communication mode	CAN&RS485
