Product Features
BMS Protection
Overcharge/Over-discharge Protection, Charge/Discharge Over-current Protection, Short-circuit Protection, Battery Voltage Self-balancing, High-temperature Discharge Cut-off.
High Capacity andLightweightCompact size and easy to move, making it an ideal choice
for indoor power supply
Wide Range of Applications Long Lifespan
Easy Installation Multi-Brand Compatibility
Capacity Expansion
Suitable for off-grid or hybrid systems.
Can be cycled up to 6000 times (280Ah) / 8000 times (314Ah). Supports floor-standing installation.
Compatible with multiple inverter protocols from various brands, and can communicate directly with computers.
Up to 15 units can be connected in parallel, expandable to 215.04kWh(280Ah) /241.15kWh(314Ah).
Smart Control
ECO-WORTHY APP.|
Model |
51.2V 280AH (A) |
51.2V 314AH (B) |
|
|
Nominal Voltage |
51.2V |
51.2V |
|
|
Nominal Capacity |
280AH |
314AH |
|
|
Nominal Energy |
14336Wh |
16077Wh |
|
|
Battery Type |
LFP |
LFP |
|
|
Cycle Life |
6000(80%DOD, 0.5C, 25℃) |
8000(80%DOD, 0.5C, 25℃) |
|
|
Maximum Number of Units in Parallel |
15 units |
||
|
Charge Cut-off Voltage |
58.4V |
||
|
Discharge Cut-off Voltage |
43.2V |
||
|
Standard Charge Current |
100A |
||
|
Maximum Charge Current |
200A |
||
|
Standard Discharge Current |
100A |
||
|
Maximum Discharge Current |
200A |
||
|
Dimensions |
807*520*252mm |
||
|
Weight |
130kg |
||
|
Communication |
CAN/RS485/RS232 |
||
|
Charging Temperature Range |
0℃~55℃ |
||
|
Discharging Temperature Range |
-20℃~60℃ |
||
|
Cooling Method |
Natural Cooling |
||
|
Protection |
Built-in Smart BMS |
||
|
IP Rating |
IP30 |
||
|
Warranty |
5 Years |
||
|
Certification |
MSDS, UN38.3, CE-EMC, IEC62619 |
||
